Nützliche ABAP Transformationsroutinen

In diesem Beitrag stelle ich Ihnen verschiedene ABAP Routinen vor. Wenn Sie diese Code Snippets implementieren, beachten Sie die Performance Richtlinien.

Interne Tabellen buffern

*In PRIVATE SECTION von CLASS lcl_transform DEFINITION.
*$*$ begin of global - insert your declaration only below this line  *-*
    CLASS-DATA: lt_global TYPE STANDARD TABLE OF sflight.
*$*$ end of global - insert your declaration only before this line   *-*


*In CLASS lcl_transform IMPLEMENTATION.
*$*$ begin of routine - insert your code only below this line        *-*
    IF lt_global[] IS INITIAL.
      SELECT * FROM sflight
      INTO TABLE lt_global.
    ENDIF.
*$*$ end of routine - insert your code only before this line         *-*

Source System aus dem Material nachlesen

DATA: lt_zmaterial TYPE HASHED TABLE OF /bic/pzmaterial
WITH UNIQUE KEY /BIC/ZMATERIAL,
ls_zmaterial TYPE /bic/pzmaterial.

IF lt_zmaterial[] IS INITIAL. "Wenn Body der Tabelle leer
* Bisher wurden keine Attribute zur Material geladen,
* daher werden jetzt alle Attribute, die aktuell
* gültig sind in die Tabelle lt_zmaterial geladen.
SELECT * FROM /bic/pzmaterial
INTO TABLE lt_zmaterial
WHERE objvers = 'A'.
ENDIF.
*den oberen Teil am besten in der Start- und Globalroutine ausführen. Performance
READ TABLE lt_zmaterial
INTO ls_zmaterial
WITH TABLE KEY
/BIC/ZMATERIAL = SOURCE_FIELDS-/BIC/ZAPOMAT.
IF sy-subrc = 0.
RESULT = ls_zmaterial-SOURSYSTEM.
ENDIF.

0FISCPER aus 0CALMONTH2 und 0CALYEAR

DATA: lv_calmonth TYPE /bi0/oicalmonth,
lv_fiscper TYPE /bi0/oifiscper.

lv_calmonth+0(4) = source_fields-calyear.
lv_calmonth+4(2) = source_fields-calmonth2.

*find out the fiscal period
IF lv_calmonth IS NOT INITIAL.
CALL METHOD cl_rsar_function=>calmonth_fiscper
EXPORTING
i_calmonth = lv_calmonth
i_fiscvar = 'V9' "die jeweilige Variante
IMPORTING
e_fiscper = lv_fiscper.
IF sy-subrc <> 0.
lv_fiscper = '000000'.
ENDIF.
ELSE. "lv_calmonth is initial
lv_fiscper = '000000'.
ENDIF.

RESULT = lv_fiscper.
*Anschließend können wir das Geschäftjahr bestimmen
*lv_fiscyear = lv_fiscper+0(4).

Die Funktionsgruppe ADAT enthält einige nützliche Funktionsbausteine mit Kalenderfunktionen.

0CALQUARTER aus 0CALMONTH2 und 0CALYEAR, die auch Werte 00 liefern können.

DATA: lv_calmonth TYPE /bi0/oicalmonth,
lv_calquarter TYPE /bi0/oicalquarter.

lv_calmonth+0(4) = source_fields-calyear.
lv_calmonth+4(2) = source_fields-calmonth2.

*find out the calendar quarter
IF lv_calmonth IS NOT INITIAL.
CALL METHOD cl_rsar_function=>month_quarter
EXPORTING
i_month = lv_calmonth
IMPORTING
e_quarter = lv_calquarter.
IF sy-subrc <> 0.
lv_calquarter = '00000'.
ENDIF.
ELSE. "lv_calmonth is initial
lv_calquarter = '00000'.
ENDIF.

RESULT = lv_calquarter.

Nur Großbuchstaben verwenden

DATA: V_TBWCPRODI TYPE /BIC/OITBWCPRODI.

* convert characters to upper-case characters
V_TBWCPRODI = SOURCE_FIELDS-/BIC/TBWCPRODI.
TRANSLATE V_TBWCPRODI TO UPPER CASE.
RESULT = V_TBWCPRODI.

Bestimmte Datensätze überspringen

DATA: lv_PARTNER TYPE string.

lv_PARTNER = SOURCE_FIELDS-PARTNER.

IF STRLEN( lv_PARTNER ) > 4.
raise exception type CX_RSROUT_SKIP_RECORD.
ELSE.
RESULT = lv_PARTNER.
ENDIF.

Die ersten zwei Nullen löschen

DATA: lv_PARTNER TYPE string.
lv_PARTNER = SOURCE_FIELDS-PARTNER.

SHIFT lv_PARTNER BY 2 PLACES LEFT.
RESULT = lv_PARTNER.

15-Stelliges Timestamp in 8-Stelliges Datenfeld umwandeln

DATA: lv_CHANGED_ON TYPE string.

lv_CHANGED_ON = SOURCE_FIELDS-CHANGED_ON.

IF STRLEN( lv_CHANGED_ON ) >= 8.
RESULT = lv_CHANGED_ON+0(8).
ELSE.
RESULT = '00000000'.
ENDIF.

0CALMONTH2 und 0CALYEAR zu 0CALMONTH

data l_calmonth type /BI0/OICALMONTH.
l_calmonth+0(4) = SOURCE_FIELDS-CALYEAR.
l_calmonth+4(2) = SOURCE_FIELDS-CALMONTH2.

RESULT = l_calmonth.

0FISCPER Jahr immer 2012, z.B. um Testdaten aus IDEA zu laden

DATA: lv_year TYPE /bi0/oifiscyear,
lv_per TYPE /bi0/oifiscper3.

* lv_year = source_fields_rule-perio+0(4).
lv_year = 2012.
*lv_year + 3.
lv_per = source_fields_rule-perio+4(3).

CONCATENATE lv_year lv_per INTO RESULT.

0CALMONTH im DTP-Filter per Routine auf den aktuellen Kalendarjahr/monat setzen.

form c_CALMONTH
tables l_t_range structure rssdlrange
using i_r_request type ref to IF_RSBK_REQUEST_ADMINTAB_VIEW
i_fieldnm type RSFIELDNM
changing p_subrc like sy-subrc.
* Insert source code to current selection field
*$*$ begin of routine - insert your code only below this line *-*

DATA: rec LIKE LINE OF l_t_range.

rec-iobjnm = '0CALMONTH'.
rec-fieldname = 'CALMONTH'.
rec-sign = 'I'.
rec-option = 'EQ'.
rec-low = sy-datum+0(6).
APPEND rec TO l_t_range.

*folgendes sollte auch gehen, ohne rec
*  l_t_range-iobjnm = '0CALMONTH'.
*  l_t_range-fieldname = 'CALMONTH'.
*  l_t_range-sign = 'I'.
*  l_t_range-option = 'EQ'.
*  l_t_range-low = sy-datum+0(6).
*  APPEND l_t_range.
*$*$ end of routine - insert your code only before this line *-*
endform.

Vormonat ermitteln

DATA: lv_datum TYPE d.
lv_datum = sy-datum.
lv_datum+6(2) = '01'.
lv_datum = lv_datum - 1.

InfoPackage Routine Selektion von dem aktuellen Monat bis 2099

  DATA:  l_idx LIKE sy-tabix,
         rec LIKE LINE OF l_t_range.
  READ TABLE l_t_range WITH KEY
       fieldname = 'CALMONTH'.
  l_idx = sy-tabix.
  rec-iobjnm = '0CALMONTH'.
  rec-fieldname = 'CALMONTH'.
  rec-sign = 'I'.
  rec-option = 'BT'.
  rec-low = sy-datum+0(6).
  rec-high = '209912'.
  MODIFY l_t_range INDEX l_idx FROM rec.
  p_subrc = 0.

Unerlaubte Zeichen entfernen

 DATA: l_d_offset LIKE sy-index.
CONSTANTS: c_allowed(100) TYPE c
value 'ABCDEFGHIJKLMNOPQRSTUVWXYZ1234567890_'.
RESULT = SOURCE_FIELDS-/BIC/NAME.
* Es sind nur Großbuchstaben erlaubt, also Umwandlung in Großbuchstaben.
TRANSLATE RESULT TO UPPER CASE.
DO 60 TIMES.
l_d_offset = sy-index – 1.
IF RESULT+l_d_offset(1) CO c_allowed.
* Erlaubtes Zeichen, mache nichts
ELSE.
* Zeichen nicht erlaubt, ersetzen durch Leerzeichen
RESULT+l_d_offset(1) = ' '.
ENDIF.
ENDDO.

Unerlaubte Zeichen entfernen 2
Umgekehrter Ansatz


lv_TBWCSPORT = <result_fields>-/BIC/TBWCSPORT.

TRANSLATE lv_TBWCSPORT  to upper case.

REPLACE ALL OCCURRENCES OF REGEX
'[^!"%&''()*+,-./:;<=>?_ 0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZ.]'
IN
lv_TBWCSPORT with '_'.

<result_fields>-/BIC/TBWCSPORT = lv_TBWCSPORT.

Mit Nullen auffüllen

SHIFT lv_matnr RIGHT DELETING TRAILING SPACE.
OVERLAY lv_matnr WITH '000000000000000000'.
*Für rein numerische matnr könnte man auch
*UNPACK LV_MATNR TO LV_MATNR. verwenden

Oder Alpha Conversion

    CALL FUNCTION 'CONVERSION_EXIT_ALPHA_INPUT'
      EXPORTING
        input  = SOURCE_FIELDS-/bic/zmatnr
      IMPORTING
        output = RESULT.

Letztes Zeichen löschen

  DATA:
    lv_len     TYPE i,
    lv_line    TYPE string.

  lv_len = strlen( lv_line ).
  lv_len = lv_len - 1.
  lv_line = lv_line+0(lv_len).

Technische User nicht laden – DTP Variable

  data: l_idx     like sy-tabix,
        l_s_range like LINE OF l_t_range.

  read table l_t_range with key
        fieldname = 'CUSER'.
  l_idx = sy-tabix.

*Exclude Technical Users
  l_s_range-iobjnm    = '0USERNAME'.
  l_s_range-fieldname = 'CUSER'.
  l_s_range-SIGN      = 'E'.
  l_s_range-OPTION    = 'CP'.
  l_s_range-low       = 'ALE_*'.
  append l_s_range to l_t_range.

  if l_idx <> 0.
    modify l_t_range index l_idx.
  else.
    append l_t_range.
  endif.
  p_subrc = 0.

Konten- zu Kennzahlenmodell
Transformation zur InfoSource. Konten(ZGRP_KPI) und Kennzahlen (ZSTRLC) des Kontenmodells in der InfoSource.

loop at RESULT_PACKAGE assigning <RESULT_FIELDS>.
IF <RESULT_FIELDS>-/BIC/ZGRP_KPI = '201'.
<RESULT_FIELDS>-/BIC/ZGRSA1 = <RESULT_FIELDS>-/BIC/ZSTRLC.
ELSEIF <RESULT_FIELDS>-/BIC/ZGRP_KPI = '202'.
<RESULT_FIELDS>-/BIC/ZDISC1 = <RESULT_FIELDS>-/BIC/ZSTRLC.
ELSEIF <RESULT_FIELDS>-/BIC/ZGRP_KPI = '203'.
<RESULT_FIELDS>-/BIC/ZNETS1 = <RESULT_FIELDS>-/BIC/ZSTRLC.
ELSEIF <RESULT_FIELDS>-/BIC/ZGRP_KPI = '247'.
<RESULT_FIELDS>-/BIC/ZSALM1 = <RESULT_FIELDS>-/BIC/ZSTRLC.
ELSEIF <RESULT_FIELDS>-/BIC/ZGRP_KPI = '301'.
<RESULT_FIELDS>-/BIC/ZNETQ1 = <RESULT_FIELDS>-/BIC/ZSTRQTY.
ENDIF.
endloop.

Dateinamen aus Datum (für DTPs oder InfoPackages)

  DATA: lv_vortag TYPE sy-datum.
  lv_vortag = sy-datum - 1.
  CONCATENATE '/tmp/actuals_' lv_vortag '.csv' INTO p_filename.

Testdaten aus vorhandenen Daten generieren (Feldroutinen)


DATA lv_fiscper TYPE /bi0/oifiscper.
lv_fiscper = source_fields_rule-fiscper.
REPLACE '2019' IN lv_fiscper WITH '2020'.
result = lv_fiscper.

DATA lv_calmonth TYPE /bi0/oicalmonth.
lv_calmonth = source_fields_rule-calmonth.
REPLACE '2019' IN lv_calmonth WITH '2020'.
result = lv_calmonth.

DATA lv_calquarter TYPE /bi0/oicalquarter.
lv_calquarter = source_fields_rule-calquarter.
REPLACE '2019' IN lv_calquarter WITH '2020'.
result = lv_calquarter.

DATA: lv_percentage TYPE i,
lv_trnover TYPE /bic/oizdtrnover.
DATA(lo_rand) = cl_abap_random_int=>create( seed = CONV i( sy-uzeit )min = 1max = 100 ).
lv_percentage = lo_rand->get_next( ).
lv_trnover = source_fields_rule-/bic/zdtrnover + source_fields_rule-/bic/zdtrnover * lv_percentage / 100.
result = lv_trnover.

DTP Filter auf heute setzen

  form c_/BIC/TIMESTAMP
  tables l_t_range structure rssdlrange
  using i_r_request type ref to IF_RSBK_REQUEST_ADMINTAB_VIEW
        i_fieldnm type RSFIELDNM
  changing p_subrc like sy-subrc.

*       Insert source code to current selection field
*$*$ begin of routine - insert your code only below this line        *-*

  DATA: l_idx     LIKE sy-tabix,
        l_s_range LIKE LINE OF l_t_range.

  READ TABLE l_t_range WITH KEY
        fieldname = '/BIC/TIMESTAMP'.
  l_idx = sy-tabix.

*Todays date is set per default
  l_s_range-iobjnm    = 'TIMESTAMP'.
  l_s_range-fieldname = '/BIC/TIMESTAMP'.
  l_s_range-sign      = 'I'.
  l_s_range-option    = 'EQ'.
  l_s_range-low       = sy-datum.
  APPEND l_s_range TO l_t_range.


  IF l_idx <> 0.
   MODIFY l_t_range INDEX l_idx.
  ELSE.
    APPEND l_t_range.
  ENDIF.
  p_subrc = 0.
